309
- Lighten Up! - The front panel of 309 Gaming Edition is equipped with 144 stunning ARGB LEDs. That can achieve an excellent visual experience for the built-in games and the lighting modes.
- A TRUE Gaming Chassis! - We reinterpreted three classic games on the 309 Gaming Edition and it transforms the front panel into a gaming platform. Now you can immerse yourself in the gaming world anytime!
- 309 RACING - Being a famous racer has its challenges! You need to dodge the oncoming cars and maneuver around the oil stained roads, while trying to get to the finish line in time. Good luck!
- Exclusive Gamepad - The gamepad is specially designed for the 309’s integrated games. With its user-friendly buttons and classic design, now you can use this exclusive gamepad to gain victory!
- Lighting the Way for PC Hardware - The 309 Gaming Edition will be equipped with four InWin Saturn ASN120 fans, which feature unique transparent frames and a patented modular design.
- Create & Animate! - The upgraded GLOW X software provides the color calibration function and a new creation mode, which offers up to 40 frames, giving the user the opportunity to design whatever they want on the front panel display and can even create an animation!
- Interactive Lifestyle! - Coming with a built-in sound receiver, the 309 Gaming Edition provides interactive lighting. It hosts a virtual chicken/giraffe that reacts to noise. Just don’t be too loud or it will go crazy!
- Versatile Liquid Cooling Support - There are three locations the chassis can accommodate liquid radiators; top, bottom (slim) and rear. A total of seven 120mm case fans can be mounted.
* The addressable cable can only be used with motherboards with ARGB headers.
* The GLOW X software is the exclusive software of the 309 Gaming Edition. All previous models cannot run this version.
TECHNICAL SPECIFICATIONS
Model | 309 Gaming Edition |
Model Number | IW-CS-309GE-BLK |
Color | Black |
Case Type | Mid Tower |
Materials | SECC, Tempered Glass, ABS |
M/B Compatibility | 12" x 13" E-ATX, ATX, Micro-ATX, Mini-ITX |
Expansion Slots | 7 x PCI-E |
Maximum Compatibility | VGA Card Length: 350 mm CPU Heatsink Height: 160 mm |
I/O Ports | 1 x USB 3.1 Gen 2 Type-C 2 x USB 3.0 HD Audio LED & Fan Mode Button LED & Fan Control Buttons |
Internal Drive Bays | 2 x 3.5" / 2.5" 2 x 2.5" |
Thermal Solution Compatibility | Air Cooling Fans: Top: 3 x 120 mm Rear: 1 x 120 mm Bottom: 3 x 120 mm (4 InWin Saturn ASN120 Fans Included) Water Cooling Radiator: Top: 1 x 360 mm Rear: 1 x 120 mm Bottom: 1 x 360 mm (Slim) |
Power Supply Compatibility | PSII: ATX12V - Length up to 200 mm |
Product Dimensions (L x W x H) | 553 x 238 x 500 mm 21.8 x 9.4 x 19.7" |
Package Dimensions (L x W x H) | 706 x 618 x 335 mm 27.8 x 24.4 x 13.2" |
Net Weight | 13.7 kg / 30.1 lbs |
Gross Weight | 16.6 kg / 36.6 lbs |
* Number of fans pre-installed may vary based on different regions.
* InWin products comply with RoHS regulation.
.
