FRACTAL DESIGN vodní chlazení Celsius S24

Kód: 497235
Na dotaz
Termín a způsob doručení
Typ chladiče:Vodní; Využití chladiče:Na procesory; Velikost ventilátoru:120x120; Barva podsvícení:bez podsvícení.Více
Vyberte si zvýhodněné balení
Množstevní slevy
3 019
2 495.04  bez DPH
Běžná cena: NaN
ks
envelope
Dotaz
bell
Hlídat
Parametry
Výrobce:
Kód:
497235
EAN:
7350041084457
Záruka:
24 Měsíc(ů)
Využití chladiče:
Na procesory
Typ chladiče:
Vodní
Barva podsvícení:
bez podsvícení
Velikost ventilátoru:
120x120
Popis FRACTAL DESIGN vodní chlazení Celsius S24

The Celsius series builds upon proven technology with cutting edge advancements and premium sound dampening materials to deliver extreme cooling performance with minimum noise output.

Smart dual mode speed controls are both simple and robust with no need for additional software. Both fan and pump speeds can be managed by an intelligent auto mode or switched to PWM mode for precise user control.

For true enthusiasts, the satisfaction of a clean and efficient build can never be overstated, and the Celsius makes this easier than ever with an integrated fan hub and concealed cable routing.

Key features:

The Celsius series uses a combination of cutting edge technology and premium sound dampening materials to deliver extreme cooling performance with minimum noise output. An intelligent temperature-controlled auto mode adjusts fan and pump speeds in real-time for optimum balance of cooling performance and silence, while PWM mode enables precision manual tuning for any usage situation. Included Fractal Design Dynamic X2 PWM fans offer a wide speed adjustment range from 500 to 2000 RPM allowing for near silent operation under lighter loads and maximum airflow during heavy usage. An integrated fan hub with concealed cable routing simplifies cable management for a clean installation. Radiator fittings use standard G 1/4" thread for maximum compatibility and expandability with standard do-it-yourself components. Easily add and integrate a GPU block of your choice to eliminate noisy graphics card fans so the only sound you hear is the sound of your game.

General Specification

Coldplate technology

Fifth generation

Coldplate material

Copper

Additional sound dampening

Integrated

Thermal paste

Pre-applied, high thermal conductivity

Sockets supported (Intel)

1150, 1151, 1155, 1156, 1366, 2011, 2011-v3

Sockets supported (AMD)

AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+

Tube length

400 mm

Tube material

Sleeved low-permability rubber tubes

Fittings, block side

Durable metal fittings, non-removable

Fittings, radiator side

Durable metal fittings, G 1/4" thread

Thermal paste

Pre-applied, high thermal conductivity

Fan control

Integrated dual mode

Warranty

5-year (Upon Expansion of the Celsius unit, only individual components of the Fractal Design Celisus S24 or S36 are covered)

Fan specification

Fan type

Fractal Design Dynamic X2 GP-12 PWM

Rotational speed

500-2000 RPM

Bearing

LLS bearing

PWM control

Yes

Acoustical noise (full speed)

32.2 dB(A)

Maximum air flow

148.8 m3/h | 87.6 CFM

Maximum static pressure

2.30 mm H2O

Input voltage

12 V DC

Maximum input current

0.2A

MTBF

>100,000

Pump specification

Rotational speed

1950-3150 RPM

Bearing type

Ceramic bearing and shaft

PWM control

Yes

Acoustical noise (full speed)

20,0 dB(A)

Maximum pressure, 50°C

1m H2O | 1.45 PSI

Input voltage

12 V DC

Input current (without fans)

0.15 A

Rated input power (with fans)

6.6W

MTTF

>50,000 hours

Radiator specification

Dimensions

284*122*31 mm

Housing material

Aluminium

Fin material

Aluminium

Port threads

G 1/4"

Fan screw threads

UNC 6-32

Package contents

Celsius S24 system

2 pcs Dynamic X2 GP-12 PWM fans

Multilingual user manual

Mounting hardware for all listed sockets

Fan and radiator mounting screws

Additional information

EAN: 7350041084457

UPC: 817301014458

Product code: FD-WCU-CELSIUS-S24-BK

.
