Club3D adaptér aktivní HDMI na DisplayPort 4K60Hz, M/F

Kód: 795131
Skladem>5ks
Termín a způsob doručení
Specifikace kabelu / redukce:Adaptér, Redukce; Input:USB, HDMI; Output:DisplayPort.Více
Vyberte si zvýhodněné balení
Množstevní slevy
999
825.62  bez DPH
Běžná cena: NaN
ks
envelope
Dotaz
bell
Hlídat
Parametry
Výrobce:
Kód:
795131
EAN:
8719214471484
Záruka:
24 Měsíc(ů)
Specifikace kabelu / redukce:
Adaptér, Redukce
Input:
HDMI, USB
Output:
DisplayPort
Popis Club3D adaptér aktivní HDMI na DisplayPort 4K60Hz, M/F

HDMI™ to DisplayPort™ 4K60Hz M/F Active

The Club 3D CAC-1331 is an HDMI™ to DisplayPort™ 1.2 Active Adapter which allows you to transmit a HDMI™ signal into a DisplayPort™signal. This product supports DP1.2 specification with resolution up to 4096 x 2160@60Hz. Besides, it is equipped with USB Type A port to supply power in case there isn’t enough power from the HDMI™ source. This Adapter is Uni-Directional.

Please use one of our (Extension)HDMI™ and/or DisplayPort™ cables to connect from the adapter to your devices: In case you need assistance to choose the correct cable, please visit our website www.club-3d.com or feel free to mail us at support@club-3d.com and it will be our pleasure to assist you.


TECHNICAL SPECIFICATIONS

Product Name HDMI™ to DisplayPort™ 1.2 4K60Hz M/F Active Adapter
Product Series Adapter
Itemcode CAC-1331
EAN code 8719214471484
UPC code 841615101665
Features
  • HDMI™ 2.0 support:
    - HDCP1.4/2.2
    - 8/10/12-bit Deep Color
    - Status and Control Data Channel (SCDC)

  • DisplayPort™ 1.2 support:
    - DP1.2a compliant
    - Resolution up to 4K60Hz
    - Support Four Lanes with 1.62Gbps (RBR), 2.7Gbps (HBR) or 5.4Gbps (HBR2) Data Rate
    - Support 8/10/12-bit Deep Color
    - Support Hot-Plug Detect

  • Gold plated connectors
OS Support
  • All
In the box
  • CAC-1331 - HDMI™ to DisplayPort™ 1.2 4K60Hz M/F Active adapter
Input
  • 1x HDMI™ (Male)
  • 1x USB Type A for power
Output
  • DisplayPort™ 1.2 (Female)
Other info
  • Box size 14.5 x 14.5 x 3 cm
  • Box size: 5.7 x 5.7 x 1.2 inch
  • Device size: 2 x 1.1 x 25 cm
  • Device size: 0.8 x 0.4 x 9.84 inch
  • Device Weight: 42 gr / 1.5 oz:
  • Total Cable length 25 cm / 9.84 inch
  • Connector dimensions :
  • HDMI™ Male 4.8 x 1.1 x 2.1 cm / 1.89 x 0.43 x 0.83 inch
  • DisplayPort™ Female 2 x 3.5 x 1.1 cm / 0.79 x 1.38 x 0.43 inch
  • USB Type A Male 3.7 x 0.7 x 1.5 cm / 1.46 x 0.28 x 0.6 inch
  • Box Weight: 18 gr / 0.7 oz
  • Total Weight: 60 gr / 2.2 oz
  • Meets ROHS, FCC, and CE EMI requirements


In case of technical questions, you can contact the official support of the Club 3D manufacturer by email: support@club-3d.com. Support works mainly in English, but you can also write a question in Czech and the manufacturer will handle it. The manufacturer will respond within 24 hours. It is also possible to visit the discussion at the link: https://insights.club-3d.com/. Where you can also find useful information on using Club 3D products.
.
