| 3Model | CNPS17X |
|---|---|
| Socket Type | Intel : LGA2066/2011-V3/2011/115X CPUs  AMD : AM4/AM3+/AM3 CPUs  |
| Dimensions | 140(L) x 100(W) x 160(H)mm |
| Weight | 700g |
| Materials | Pure Copper, Pure Aluminum |
| Heatpipe | 5 |
| Heat Dissipation Area | 6,243cm3 |
| TDP | 200W |
| Bearing Type | FDB(Fluid Dynamic Bearing) |
| Fan Speed | 800~1,500 RPM ±10% |
| Max Noise Level | 29.0 dB(A) ±10% |
| Max Airflow | 61CFM |
| Max. Air Pressure | 1.1mm H2O |
| Life Span | 100,000 hours |
| Power Consumption | Fan : 3.36W  LED : 1.5W  |
| Rated Voltage | Fan : 12V  LED : 5V  |
| Rated Current | Fan : 0.28A  LED : 0.3A  |
| Fan Connector Type | Fan : 4-Pin PWM  LED : 3-Pin Addressable  |
.
